Unit Type: Conventional / Fixed Type

Rated horse power: 1.0 HP

Cooling Capacity: 9495 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 853 W

Air Flow Volume: 520/470/420/290/250 m³/h

INDOOR UNIT:
Sound Pressure Level: 39/36/32/30/29 dB(A)

Dimension (WxHxD): 704×260×185 mm

Net Weight / Gross Weight: 7.5 / 9 kg

OUTDOOR UNIT:
Sound Pressure Level: 48 dB(A)

Dimension (WxHxD): 710×450×293 mm

Net Weight / Gross Weight: 21 / 23 kg

Refrigerant: R32

Unit Type: Conventional / Fixed Type

Rated horse power: 1.5 HP

Cooling Capacity: 12418.41 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 1180 W

Air Flow Volume: 590/520/440/350/330 m³/h

INDOOR UNIT:
Sound Pressure Level: 41/37/34/30/28 dB(A)

Dimension (WxHxD): 779×260×185 mm

Net Weight / Gross Weight: 8.5 / 10 kg

OUTDOOR UNIT:
Sound Pressure Level: 50 dB(A)

Dimension (WxHxD): 710×450×293 mm

Net Weight / Gross Weight: 24.5 / 26.5 kg

Refrigerant: R32

Unit Type: Conventional / Fixed Type

Rated horse power: 2.0 HP

Cooling Capacity: 18990 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 1760 W

Air Flow Volume: 900/800/700/630/600 m³/h

INDOOR UNIT:
Sound Pressure Level: 42/40/35/32/31 dB(A)

Dimension (WxHxD): 982×311×221 mm

Net Weight / Gross Weight: 14 / 16.5 kg

OUTDOOR UNIT:
Sound Pressure Level: 55 dB(A)

Dimension (WxHxD): 802×555×350 mm

Net Weight / Gross Weight: 34.5 / 37 kg

Refrigerant: R32

Unit Type: Conventional / Fixed Type

Rated horse power: 2.5 HP

Cooling Capacity: 25917.13 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 2142 W

Air Flow Volume: 1250/1100/950/850/800 m³/h

INDOOR UNIT:
Sound Pressure Level: 46/43/39/36/35 dB(A)

Dimension (WxHxD): 1075×333×246 mm

Net Weight / Gross Weight: 17 / 20 kg

OUTDOOR UNIT:
Sound Pressure Level: 56 dB(A)

Dimension (WxHxD): 958×660×402 mm

Net Weight / Gross Weight: 43.5 / 48 kg

Refrigerant: R32

Unit Type: Conventional / Fixed Type

Rated horse power: 3.0 HP

Cooling Capacity: 28787.28 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 2350 W

Air Flow Volume: 1400/1050/950/870/850 m³/h

INDOOR UNIT:
Sound Pressure Level: 51/43/41/38/37 dB(A)

Dimension (WxHxD): 1075×333×246 mm

Net Weight / Gross Weight: 16 / 19 kg

OUTDOOR UNIT:
Sound Pressure Level: 55 dB(A)

Dimension (WxHxD): 958×660×402 mm

Net Weight / Gross Weight: 49 / 53.5 kg

Refrigerant: R32

Unit Type: Conventional / Fixed Type

Rated horse power: 3.0 HP

Cooling Capacity: 28801.5 kJ/h

Power Supply: 230 V, 60 Hz, 1 Ph

Cooling Power Input: 2470 W

Air Flow Volume: 1250/1100/900/800/ m³/h

INDOOR UNIT:
Sound Pressure Level: 50/47/42/39/ dB(A)

Dimension (WxHxD): 1078×325×246 mm

Net Weight / Gross Weight: 16.5 / 20 kg

OUTDOOR UNIT:
Sound Pressure Level: 56 dB(A)

Dimension (WxHxD): 1080×485×840 mm

Net Weight / Gross Weight: 65 / 70 kg

Refrigerant: R410A
